| Place of Origin: | Zhejiang, China |
|---|---|
| Brand Name: | Yade |
| Model Number: | 20442-26-10T |
| Minimum Order Quantity: | 100 Pieces |
| Price: | be negotiation |
| Material: | Carbon Steel | Technics: | Forged |
|---|---|---|---|
| Connection: | Female | Shape: | Reducing |
| Head Code: | Square | Product Name: | Metric Female O-ring Hydraulic Spare Parts |
| The Color Of Zinc: | Yellow Or White | The Charge Of Samples: | Free Samples Can Be Supply To Customer |
| Raw Material: | 45# Or 20# Carbon Steel | Label On Carton: | Item No.: QTY.Weight,CTNS |
| DN: | 6-50mm | Pressure: | 30-50Mpa |
| Keyword: | Banjo Hydraulic Fittings | Selling Units: | Single Item |
| Single Package Size : | 25X22X12 Cm | Single Gross Weight: | 0.100 Kg |
| Package Type: | Neutral Package: Carton Box +pallet +plywood Case | ||
| High Light: | metric din fittings,metric hose fittings |
||
metric female o-ring hydraulic spare parts female threaded pipe connection fittings
| PART NO. | THREAD E | DN | DASH | TUBE O.D. | O RING | A | C | H | S2 |
| 20441-14-04 | M14*1.5 | 6 | 4 | 8 | O6.5*1.5 | 49 | 2 | 27 | 19 |
| 20441-16-05 | M16*1.5 | 8 | 5 | 10 | O8.0*1.5 | 51.5 | 2 | 28.2 | 22 |
| 20441-16-06 | M16*1.5 | 10 | 6 | 10 | O8.0*1.5 | 53.4 | 2 | 29.2 | 22 |
| 20441-18-05T | M18*1.5 | 8 | 5 | 12 | O10.0*1.5 | 46.2 | 2.5 | 22.9 | 22 |
| 20441-18-06 | M18*1.5 | 10 | 6 | 12 | O10.0*1.5 | 54.2 | 2.5 | 29.9 | 24 |
| 20441-22-05T | M22*1.5 | 8 | 5 | 15 | O12.0*2.0 | 48.3 | 2.5 | 25 | 27 |
| 20441-22-06T | M22*1.5 | 10 | 6 | 15 | O12.0*2.0 | 50.4 | 2.5 | 25.7 | 27 |
| 20441-22-08 | M22*1.5 | 12 | 8 | 15 | O12.0*2.0 | 68.1 | 2.5 | 33.2 | 27 |
| 20441-26-08T | M26*1.5 | 12 | 8 | 18 | O15.0*2.0 | 62 | 2.5 | 26.1 | 32 |
| 20441-26-10 | M26*1.5 | 16 | 10 | 18 | O15.0*2.0 | 80.7 | 2.5 | 35.9 | 32 |
| Type: | Hydraulic Hose Fitting |
| Material: | Carbon Steel ,Stainless Steel |
| Coating: | Yellow or White Zinc Plated |
| Carton Size: | 25*22*12 |
| Pallet Size: | 100Cm*100CM*80CM |
| Delivery Time: | 30 Days after receipt of deposit Payment |
metric ferrule fittings reusable hose fitting 20111-24-08---Our Factory is specialized in makingHydraulic Fittings, Hydraulic Hose Fittings, Hose Fititngs, Hydraulic Adapters, Hydraulic Adaptors and so on.
Q: How about payment?
A: For large orders, T/T, L/C. For small orders, credit cards are accepted (SHOULD SPECIFY HERE WHICH CC PAYMENT SYSTEMS ARE ACCEPTABLE: MASTER CARD, VISA, AMERICAN EXPRESS, ETC.)
Q: What about shipping?
A: We ship small batches by air,or larger orders by container. In any event, we get quality product out the door quickly.
Q: Can you provide certificates?
A: Yes, certainly, we can supply ISO 9001 certificates.
If you have any other questions,please do not hesitate to contact us!
