| Place of Origin: | Zhejiang, China |
|---|---|
| Brand Name: | YADE |
| Model Number: | Reusable hose fittings |
| Minimum Order Quantity: | 100 Pieces |
| Price: | be negotiation |
| Product Name: | JIC Reusable Hose Fittings | Model: | JIC One Piece Fittings |
|---|---|---|---|
| Material: | Stainless Steel Or Carbon Steel | Suitable Medium: | Water / Oil / Gas |
| Technics: | Hot Forge ,CNC Machine | Surface Treatment: | Trivalent Zinc Plated |
| Application: | Industry Excavator | Assemble Way: | Crimp,lock On |
| Size: | 1/4"-2" | Type: | Hydraulic Filters |
| Package Type: | Neutral Export Package: Carton Box With Plastic Bag Then Into Woodem Plastic | ||
| High Light: | male bsp hydraulic hose fittings,female bsp hydraulic hose fittings,90 degree bsp hydraulic fittings |
||
Product Name
Hot Sale Eaton 90 Degree Hydraulic Air Hose Fittings Male Female JIC BSP Hydraulic Hose Fittings
| Part Number | Thread | Hose ID | Size A | Size B | Size E | Hexagon | Ferrule ID | Ferrule O.D | |||||||
| inch | inch | mm | mm | mm | W | mm | mm | ||||||||
| 13943-04-04 | 7/16"-20 | 1/4 | 57 | 30 | 33 | 17 | 16.6 | 24 | |||||||
| 13943-06-06 | 9/16"*18 | 3/8 | 69 | 32 | 39 | 19 | 21 | 28 | |||||||
| 13943-08-08 | 3/4"*16 | 1/2 | 77 | 33 | 47 | 24 | 23.6 | 31.5 | |||||||
| 13943-12-12 | 1.1/16"*12 | 3/4 | 112 | 42.5 | 63 | 32 | 32 | 40 | |||||||
| 13943-16-16 | 1.5/16"*12 | 1 | 120 | 51 | 70 | 41 | 39.7 | 49 |
