| Place of Origin: | China |
|---|---|
| Brand Name: | None |
| Model Number: | Z1-22 |
| Minimum Order Quantity: | 1 pcs |
| Price: | be negotiation |
| Packaging Details: | 1 PCS PACKED INDIVIDUALLY IN 1 BOX |
| Delivery Time: | 10-25 days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 100000pcs/month |
| Model Number:: | Z1-22 | Pressure:: | Up To 25Mpa |
|---|---|---|---|
| Advantage: | Easy To Replace Without Dismantling The Pump Part | Application: | Grundfo Pump Or CR Pump |
| Medium: | Water,Oil And Other Low Corrosion Mediums | Keywords: | Single Mechanical Seal |
| High Light: | submersible pump single cartridge seal,pump single cartridge mechanical seal,25Mpa single cartridge mechanical seal |
||
We are manufacture mechanical seal metal structural parts and complete sets of machinery and seal ,we own our engineer department that can supply OEM products to customers ,we can be designed standard or NON-standard proudcts ,and stainless steel processing and manufacturing according to customers' samples and drawings
|
Descripthin
|
Material
|
Material Feature & Suitable Scope
|
|
Rotary / Stationary Face
|
Carbon
|
Resistant against:erosive heat
|
|
suitable for water and oil medium
|
||
|
Ceramic
|
Resistant against:shore hardness,abrasion
|
|
|
Suitable for dusted water and oil
|
||
|
Silicon Carbide
|
Resistant against: heat abrasion ,erosive
|
|
|
Suitable for industrial pumps,submersible
|
||
|
Pump sewage pump etc
|
||
|
Tungsten carbide
|
Resistant against: heat,abrasion ,erosive
|
|
|
Suitable for industrial pumps,submersible
|
||
|
Pump sewage pump ets
|
||
|
Bellow cup gasket Oring
|
NBR
|
Resistant against: pressure,abrasion high elasticity and mechanical strength
|
|
Suitable for Water and oil Under -20--120 degree
|
||
|
EPDM
|
Resistant against: heat freeze,chemical reagent depeding
|
|
|
Suitable for water and oil under-40--150 degree
|
||
|
MVQ
|
Resistant against: heat,oil reagent medicine
|
|
|
Acetone,suitable for high temperature
|
||
|
Hydraulic equipment and vacum equipment
|
||
|
Suitable for erosive medium under-20--180 degree
|
||
|
ECO
|
Resistant against:ozone aging merely ocetum,ammomia ethanol,suitable for medium-40--150degree
|
|
|
SUS 304
|
Resistant aginst: freon rock oil
|
|
|
SUS316
|
Suitable for medium-30 --130 degree
|
