| Place of Origin: | China |
|---|---|
| Brand Name: | None |
| Model Number: | GLF-12-3R |
| Minimum Order Quantity: | 1 pcs |
| Price: | be negotiation |
| Packaging Details: | 1 PCS PACKED INDIVIDUALLY IN 1 BOX |
| Delivery Time: | 10-25 days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 100000pcs/month |
| Product Name: | Mechanical Seal | Model Number:: | GLF-12-3R |
|---|---|---|---|
| Pressure:: | Up To 25 Mpa | Advantage: | Easy To Replace Without Dismantling The Pump Part |
| Application: | Grundfo Pump Or CR Pump | Medium: | Water,Oil And Other Low Corrosion Mediums |
| High Light: | GLF-12 Mechanical Seals,12mm Mechanical Seals,GLF-12-3R Mechanical Seals |
||
we're a factory which professional production the mechanical seal metal structural parts and complete sets of machinery and seals for more than 15 years ,we own our professional engineer department that can supply OEM products.
The main products are: fastening ring, transmission seat,driving ring,spring seat,shaft gland ,punching parts and all kinds of standard ,non-standard mechanical seals.
Our advantage product is Grundfos seals,the type as GLF01.GLF02.GLF03,GLF04,GLF05.GLF06,GLF-12.GLF-22,GLF-32,GLF-36,GLF-43,GLF-48 etc.
|
Temperature
|
-30 to 200 degree ,depend to the elastomer
|
|
Pressure
|
up to 10 bar
|
|
Speed
|
up to 15 m/s
|
|
End play/axial float allowance
|
+/-0.1mm
|
|
Size
|
12mm
|
|
Face
|
carbon, TC.SIC
|
|
Seat
|
Ceramic ,SIC,TC
|
|
Elastomer
|
VITON
|
|
Spring
|
SS304
|
|
Metal parts
|
SS304
|
