| Place of Origin: | Zhejiang, China |
|---|---|
| Brand Name: | none |
| Certification: | none |
| Minimum Order Quantity: | 1-99 Pieces |
| Price: | be negotiation |
| Product Name: | Hydrolic Fittings | Name: | Hose Adaptors |
|---|---|---|---|
| Material: | Carbon Steel Stainless Steel | Application: | Construction Machinery |
| Surface Treatment: | Cr3+ | Thread: | BSP Hydrolic Fittings |
| Size: | 1"-3/4" | Package: | Neutral Package |
| MOQ: | 100 | HS Code: | 73079900 |
| After Warranty Service: | Spare Parts | Condition: | New |
| Local Service Location: | None | Showroom Location: | None |
| Warranty: | 1.5 Years | Type: | Fittings |
| Pressure: | Crimp | Structure: | None |
| Weight: | 0.23 Kgs | Power(W): | High Pressure |
| Dimension(L*W*H): | None | Selling Units: | Single Item |
| Single Package Size : | 0.14X0.13X0.1 Cm | Single Gross Weight: | 0.230 Kg |
| Package Type: | Neutral Export Package | ||
| High Light: | o ring adapter,45 degree hose connector |
||
1B barbed male hose adaptor hydraulic fittings
| Item No.: | Thread | Dimension | ||||
| E | F | A | B | L | S1 | |
| 1B-02 | G1/8"*28 | G1/8"*28 | 10 | 10 | 26 | 14 |
| 1B-02-04 | G1/8"*28 | G1/4"*19 | 10 | 12 | 28 | 19 |
| 1B-02-06 | G1/8"*28 | G3/8"*19 | 10 | 13.5 | 31.5 | 22 |
| 1B-02-08 | G1/8"*28 | G1/2"*14 | 10 | 16 | 36 | 27 |
| 1B-04 | G1/4"*19 | G1/4"*19 | 12 | 12 | 30 | 19 |
| 1B-04-06 | G1/4"*19 | G3/8"*19 | 12 | 13.5 | 33.5 | 22 |
| 1B-04-08 | G1/4"*19 | G1/2"*14 | 12 | 16 | 38 | 27 |
| 1B-04-10 | G1/4"*19 | G5/8"*14 | 12 | 17.5 | 39.5 | 30 |
| 1B-04-12 | G1/4"*19 | G3/4"*14 | 12 | 18.5 | 41.5 | 32 |
| 1B-06 | G3/8"*19 | G3/8"*19 | 13.5 | 13.5 | 35 | 22 |
| 1B-06-08 | G3/8"*19 | G1/2"*14 | 13.5 | 16 | 39.5 | 27 |
| 1B-06-10 | G3/8"*19 | G5/8"*14 | 13.5 | 17.5 | 41 | 30 |
| 1B-06-12 | G3/8"*19 | G3/4"*14 | 13.5 | 18.5 | 43 | 32 |
| 1B-06-16 | G3/8"*19 | G1"*11 | 13.5 | 20.5 | 47 | 41 |
| 1B-08 | G1/2"*14 | G1/2"*14 | 16 | 16 | 42 | 27 |
| 1B-08-10 | G1/2"*14 | G5/8"*14 | 16 | 17.5 | 43.5 | 30 |
| 1B-08-12 | G1/2"*14 | G3/4"*14 | 16 | 18.5 | 45.5 | 32 |
| 1B-08-16 | G1/2"*14 | G1"*11 | 16 | 20.5 | 50 | 41 |
| 1B-08-20 | G1/2"*14 | G1.1/4"*11 | 16 | 20.5 | 53.5 | 50 |
| 1B-10 | G5/8"*14 | G5/8"*14 | 17.5 | 17.5 | 45 | 30 |
| 1B-10-12 | G5/8"*14 | G3/4"*14 | 17.5 | 18.5 | 47 | 32 |
| 1B-10-16 | G5/8"*14 | G1"*11 | 17.5 | 20.5 | 51.5 | 41 |
| 1B-10-20 | G5/8"*14 | G1.1/4"*11 | 17.5 | 20.5 | 55 | 50 |
| 1B-12 | G3/4"*14 | G3/4"*14 | 18.5 | 18.5 | 48 | 32 |
| 1B-12-16 | G3/4"*14 | G1"*11 | 18.5 | 20.5 | 52.5 | 41 |
| 1B-12-20 | G3/4"*14 | G1.1/4"*11 | 18.5 | 20.5 | 56 | 50 |
| 1B-12-24 | G3/4"*14 | G1.1/2"*11 | 18.5 | 23 | 58.5 | 55 |
| 1B-16 | G1"*11 | G1"*11 | 20.5 | 20.5 | 55.5 | 41 |
| 1B-16-20 | G1"*11 | G1.1/4"*11 | 20.5 | 20.5 | 58 | 50 |
| 1B-16-24 | G1"*11 | G1.1/2"*11 | 20.5 | 23 | 60.5 | 55 |
| 1B-16-32 | G1"*11 | G2"*11 | 20.5 | 25.5 | 64 | 70 |
| 1B-20 | G1.1/4"*11 | G1.1/4"*11 | 20.5 | 20.5 | 58 | 50 |
| 1B-20-24 | G1.1/4"*11 | G1.1/2"*11 | 20.5 | 23 | 60.5 | 55 |
| 1B-20-32 | G1.1/4"*11 | G2"*11 | 20.5 | 25.5 | 64 | 70 |
| 1B-24 | G1.1/2"*11 | G1.1/2"*11 | 23 | 23 | 63 | 55 |
| 1B-24-32 | G1.1/2"*11 | G2"*11 | 23 | 25.5 | 66.5 | 70 |
| 1B-32 | G2"*11 | G2"*11 | 25.5 | 25.5 | 69 | 70 |
| 1B-40 | G2.1/2"*11 | G2.1/2"*11 | 32 | 32 | 81 | 90 |
| 1B-48 | G3"*11 | G3"*11 | 36 | 36 | 92 | 100 |
|
Ferrules
|
Metric thread hose fittings
|
British thread hose fittings
|
|
America thread hose fittings
|
Metric thread hose adapter
|
Brithsh thread hose adapter
|
|
America thread hose adapter
|
One piece hose fittings
|
Reusable hose fittings
|
we’re a factory which manufacture hydraulic hose fitting ,adaptor for more than 10 years.
2.we have hundreds sets of machines,like full automatic CNC machine
forging machine,drilling machine,bending machine,etc.
trivalent zinc plated that improved corrosion resistance,it has been tested at 120 hours white rust and 240 hours red rust.
We have large stock of all kinds of hydraulic fittings ,more than 1000 different kinds of hydraulic fittings for selection
we’re committed to meeting your deadlines and delivery requirements,our regular delivery time is 30 days
|
|
Package Way
|
Delivery Time
|
Delivery Way
|
|
Small batch
|
Carton box with plastic bag then with strapping
|
7-10 days
|
by express that like as TNT,UPS,DHL etc.
|
|
Large quantity
|
carton box with plastic bag then into wooden pallet
|
within 30 days ,or according to our stock
|
by sea
|
A: For large orders, T/T, L/C. For small orders, credit cards are accepted (SHOULD SPECIFY HERE WHICH CC PAYMENT SYSTEMS ARE ACCEPTABLE: MASTER CARD, VISA, AMERICAN EXPRESS, ETC.)
A: We ship small batches by air,or larger orders by container. In any event, we get quality product out the door quickly.
A: We are factory.
